The ASI183MC, ZWO's most sensitive camera to date with a peak absolute Q.E. of 84% in mono made possible by a back illuminated sensor.

Introducing the ASI183 camera series, the most sensitivie cameras in ZWO history. Peak Q.E. of the mono sensor reaches 84%!

Astrophotography Performance

The ASI183 cameras has a very large full well capacity（15000e） for such small pixel size, 1.6e read noise @ 30DB, and 12stops dynamic range @ Gain=0. The ASI183 cameras also utilize firmware features to minimize amplifier glow for maximum performance in astrophotography.

High Speed

Fast FPS can be used in solar and lunar imaging, as well as for live viewing/EAA.The high speed readout may also be used for real-time focusing, true lucky imaging of double stars and other small objects, planetary imaging of the major planets in the solar system, and much more.

10Bit ADC
5496×3672 19fps
3840×2160 41.04fps
1920×1080 80.10fps
1280×720 117.30fps
12bit ADC
5496×3672 19fps
3840×2160 36.12fps
1920×1080 70.48fps
1280×720 103.23fps

High QE

Sony’s back-illuminated Exmor R technology, giving it excellent Deep Sky performance. ASI183 QE peak reaches a remarkable 84%. In Ha channel, QE is still over 60%.

Having high QE means more of the light that enters your telescope and reaches the sensor is actually used. With 84% peak Q.E. and no less than ~50% within the visible spectrum, the ASI183 will utilize a high percentage of the light that reaches it, improving your signal quality.

USB 3.0 Port & ST4 Port

USB 3.0 Port: Provide 5Gb bandwidth to make it possible for ASI183 to run at 19 fps (12bit, normal mode) or 19 fps (10bit, high speed mode) at full resolution(20.18Mega).

ST4 Port: Can be used connect with auto guide port of mount, for guiding.

ASI 183MC Instruction Manual

Mechanical Drawing

What is in the box?

ASI183 box includes all necessary cables, adapters, and manuals.

Camera Technical Details

Environmental Conditions

Max FPS at Full Resolution (10-bit ADC)

Max FPS at Full Resolution (12-bit ADC)

Description

Astronomer by night, astronomer by day! Observe the closest star to Earth during the day with the Vespera solar filter. The filter allows you to observe sunspots (dark spots) that show the intensity of the Sun’s activity.

Photograph the Sun with Vespera
The Solar Pointing mode allows you to observe the Sun in almost real-time using the live display*. Capture photos at any time from the Observation tab of the Singularity mobile app.

Take several shots at different times of the day, week or month and compare your photos. Witness how the Sun’s activity changes with the appearance or disappearance of sunspots. These can have a life span of several days, more rarely several weeks.

Observe safely
The filter is made of a metalized foil with a dimming effect. It will reduce the amount of light and allow you to observe the Sun in a way that is safe for your instrument. You will be guided through every step of your adventure by the Solar Pointing mode of the Vaonis Singularity app, to ensure the observation runs smoothly and that you and your instrument are safe.

Learn more in the Vaonis blog article Observing the solar activity with Vespera.

Warnings

• Your Vespera station should never be pointed towards the sun unless a solar filter is installed.
• You can only use Vespera to observe the sun using the Solar Pointing feature of the Singularity app and the solar filter specially designed by Vaonis. The use of any other means to observe the Sun (pointing by coordinates, pointing by hand, use of any other filter, etc.) would void your warranty in the event of damage to your equipment.
• Never look directly at the sun without adequate protection. Direct observation of the sun without protection and without a solar filter, even for a short time, can lead to serious eye burns and potential loss of vision or even blindness.
• Do not attempt to open the lens ring that contains the filter

Specifications

Features

What's in the box?

• Deluxe carry case
• Deluxe carry case strap
• Comfort neck strap
• Tethered objective lens covers
• Rainguard Eyepiece Cover
• Lens Cloth

Warranty

All Vortex products are covered by the Australian Vortex VIP Warranty

Our warranty is about you, not us. It’s about taking care of you after the sale.

The VIP stands for a Very Important Promise to you, our customers. We will repair or replace your Vortex product in the event it becomes damaged or defective—at no charge to you other then return post from you to us. It doesn’t matter how it happened, whose fault it was, or where you purchased it. You can count on the VIP Warranty for all riflescopes, red dots, rangefinders, binoculars, spotting scopes and monoculars.

• Unlimited Lifetime Warranty
• Fully transferable
• No warranty card to fill out
• No receipt needed to hang on to

If you ever have a problem, no matter the cause, we promise to take care of you.

The VIP warranty does not cover loss, misuse, theft or deliberate damage to the product.

Bintel USB to Serial RS232 Cable

• Supports all standard serial devices
• USB 2.0 and USB 1.1 Compliant
• “Plug & Play”
• Connectors: 9-pin D Male to USB A Male
• Chipset: Prolific
• No IRQ, I/O address or DMA memory address needed
• Powered from USB Bus with no external power supply required
• Cable length: 1.5m
• Compatible with Windows 10 / 8.1/ 8 / 7 / Vista (32 & 64-bit), XP and Mac OS 8.6 and above

ASI585MC Pro is a new ZWO deep sky camera based on the 4k SONY CMOS sensor with a 1/1.2″ format and 2.9μm pixels. It has a super high sensitivity and a large resolution of 3840*2160 (8.29MP in total). It also features high transmission speeds – In high-speed mode, the fast frame rate can reach 47fps at full resolution! Being an entry-level DSO camera, it offers great advantages of high cost-effectiveness.

Note:

External power supplies are needed for all ASl-cooled cameras. We recommend you use a 12V@3A~5A DC adapter (D5.5×2.1mm, center pole positive) or a lithium battery with 11-14V to power the camera. You can also use ASIAlR to power the cameras. Be aware that using a power supply out of this voltage range will probably lead to irreparable damage to the camera.

One Camera for All

The STARVIS 2 technology brings ASI585MC Pro more advanced imaging performance compared to other cooled cameras. Its high frame rate makes it not only suitable for DSO photography but also solar/lunar/planetary photography.

Jupiter -Jim Rivera

Moon -Christopher Schementi

NGC3372 ( eta Carina) -Simon Lewis

M42, NGC 1976 (Great Orion Nebula) -Simon Lewis

STARVIS 2

STARVIS 2 was developed by SONY and evolved from STARVIS. It is the latest technology with a wider dynamic range and super-high sensitivity beyond the human eye. Benefiting from it, ASI585MC Pro’s sensitivity and signal-to-noise ratio is greatly improved.

Large Full Well Capacity

The back-illuminated structure improves the camera’s full well capacity. Even with unbinned 2.9μm pixels, ASI585MC Pro has a full well capacity of 40ke-, nearly 3 times that of the last-generation sensor IMX485. A larger full well capacity gets the camera higher efficiency in collecting light, can effectively restrain the highlight area from being overexposed, and also can improve the signal-to-noise ratio.

Zero Amp Glow

ASI585MC Pro exhibits extremely clean dark frames with zero amp glow! No matter how long the exposure and how high the gain value is, you can easily get clean and smooth astro images!

Note: This feature is implemented directly at the hardware level, it does not require software control.

512MB DDR3

ASI585MC Pro uses a USB 3.0 interface, along with the built-in 512MB DDR3 cache, ensuring high-speed, smooth, and stable data transmission.

USB 3.0 Port & USB 2.0 HUB

USB 3.0 Port: Provides 5Gb bandwidth to allow ASI585MC Pro to run at 47fps at 8.29MP full resolution (10bit, high-speed mode).
USB 2.0 HUB: Can be used to connect various kinds of USB devices such as EFW, guide camera, and EAF.

Two-stage TEC Cooling

Thanks to the two-stage TEC cooling, ASI585MC Pro can lower the CMOS sensor temperature to more than 35 degrees Celsius below ambient temperature, which can greatly reduce dark current generation and sensor noise even during extended exposure times.

*The Delta T 35℃ is tested at 30℃ ambient temperature. It might get down when the cooling system is working for a long time. Also, as the ambient temperature falls, the Delta T would decrease.

Below is the dark current curve of ASI585MC Pro at the temperature from -20℃ to 30℃.

Camera Performance

Low read noise, High dynamic range

The camera has a built-in HCG mode, which can effectively reduce read noise at high gain and allow the camera to maintain the same high dynamic range as it does at low gain.

When the gain reaches 252, the HCG mode will be automatically turned on and the dynamic range reaches a level close to 11bit. The read noise in this case can be as low as 0.9e.

QE (Quantum efficiency)

Based on our testing results, the QE peak value of ASI585MC Pro is 91%.

Connection Methods (Back Focus Distance: 55mm)

Connection to External Devices

Structural Dimension Diagram

In the Box

ZWO ASI585MC Pro is a perfect match for either of these APO telescopes

Product Description

New ZWO Filter Drawer Nikon with a thickness of 29mm that can be used for carrying 2” filter and connecting ASI cooled cameras to Nikon Lens.

It is compatible with all ASI cooled cameras with 17.5mm back focus distance (except ASI GT series): 1600/294/183/071/533/2600/6200/2400

It can be used with all ZWO 2” filters, including the duo-band filter, narrowband filter, IR-cut filter, etc.

If you are using 2” filters from a third party, then please make sure they meet the requirements below.

Filters are very easy and convenient to install and pull out with the ability of double strong magnetic adsorption.

The thread of the interface: M42*0.75.

You will need to use an M54M-M42F adapter (0mm) to connect the filer drawer to the full-frame camera.

Connection method:

Connecting to ASI1600/294/183/533：

Connecting to ASI6200/2400/2600/071:

*The M54M-M42F adapter is needed when connected to full frame camera ASI6200/2400.

Mechanical drawing:

ZWO FD Nikon Specifications

70mm diameter*29mm(thickness)

M42*0.75 male (external) thread (camera side)

M48*0.75 female (internal) thread (filter end)

Suitable for 2-inch astronomical filters

What’s in the box?

The New T Tilter-II adds multiple screw holes to help connect to ZWO EFW (compatible to 2” EFW filter wheel).

Replaces original T-Tilter.

The new model offers more mounting options for you ZWO camera.

Dimensions

Main body：Diameter 78mm，11mm without the T2-T2 adapter

T2-T2 adapter：Thickness 2mm

Interface: T2 (M42*0.75 thread) each side

Main Uses

Mainly used to reduce newton ring when imaging ha-solar；

Also used to adjust the camera imaging plane by rotating the six nuts in the main body when the sensor plane is uneven

Suits all ASI cameras except ASI071, ASI2600 and ASI6200, which require the 68mm Tilter.

Connecting to Camera

Cooled camera: ASI294/ASI1600/ASI183/ASI533

Non-cooled camera:

ASI294/ASI1600/ASI183/ASI174

These cameras do not need to connect to the T2-T2 adapter

ASI178/ASI290/ASI224/ASI120

These cameras need to connect to the T2-T2 adapter first.

Mechanical Drawings

In the Box

T2 tilter x 1

T2-T2 adapter x 1

Hexagon wrench x 1

Star Analyser 200

Since its launch in 2005, the Star Analyser 100 has introduced thousands of amateur astronomers worldwide to the fascinating field of spectroscopy. Over this period, the equipment used by amateurs has evolved with larger aperture telescopes, bigger camera sensors and close coupled filter wheels becoming more common. The Star Analyser 200 model has been developed with these users in mind.

Using the same Paton Hawksley high efficiency blazed diffraction grating technology as the SA100, but with double the line density. The SA200 is designed for applications where it is difficult to achieve the optimum spacing needed for the SA100. The SA200 gives the same length of spectrum at half the spacing compared with the SA100.

KENDRICK SUN FINDER: For use with filters and telescopes without a built-in solar finder
Makes locating the sun and centering it in your eyepiece a cinch! The Kendrick Sun finder projects a solar dot onto the white target which can be viewed either from the front of the finder or through the cut out on the back.

The finder comes with a double-sided adhesive foam tape to easy adhesion to a solar filter ring or another surface.

Can be mounted on any telescope

Warning:

Never look directly at the sun without correct filters.

Permanent eye damage can happen

The Celestron PowerSeeker Accessory Kit is a great way to expand the enjoyment of your telescope. Inside the plastic, foam-lined carry case you’ll find these accessories:

• 15mm Kellner Eyepiece - 1.25”
• 9mm Kellner Eyepiece - 1.25”
• #80A Blue Filter - 1.25”
• #25 Red Filter - 1.25”
• Moon Filter - 1.25”
• Microfiber Cleaning Cloth

Eyepieces - The 15mm and 9mm eyepieces can be used in any telescope with a 1.25” focuser. Each eyepiece is fully coated to improve light transmission and protect the optics. The 15mm Kellner eyepiece offers a nice medium magnification view in most telescopes, and the 9mm provides high magnifications, great for the Moon and planets, especially when seeing conditions are good.

Filters - Coloured filters can be used to bring out certain details on a planet’s surface or its cloud structure. Both planetary filters, as well as the Moon filter, can be used on any 1.25” eyepiece with the proper filter threads, so they are very versatile. Just screw one onto your eyepiece of choice and slide it into the focuser.

• The #80A is a medium-blue filter that enhances the contrast of the cloud belts on Jupiter and the polar ice caps on Saturn. It also can be used to increase contrast on the Moon if you don’t mind the color shift.
• The #25 filter is a deep red color and is a good choice when you want to define the polar ice caps on Mars. It’s also fun to use this filter when observing Jupiter. The #25 Red filter blocks quite a bit of light coming through your telescope, however, so it is best used on bright objects with larger aperture telescopes.
• The Moon filter is one of the first accessories most new amateur astronomers buy, and for good reason! It helps block out a portion of the light the Moon sends into your eyepiece so that you can see details better. You can also try this filter on Venus; it helps you see which phase she’s in.

Cleaning Cloth & Case - Keep the microfiber cleaning cloth stashed in your PowerSeeker Accessory Kit case so that it will always be handy. It’s better to use a microfiber cloth on your optics than wipes or tissue, as it will not leave a residue, and can be reused. Remember to blow or brush any dust particles off of your optics before rubbing them with the cloth.

The black plastic carry case has die-cut foam inside to protect and cushion your accessories. Keep each one in its appointed place when not in use and you’ll keep them looking and performing like new.

Wind, an unsteady tripod, or even an accidental bump can disturb your image quality. Keep your telescope still while observing with these sturdy pads. Simply place your tripod legs on top of the pads to absorb shock and stabilize your telescope.

Celestron’s set of three Vibration Suppression Pads are manufactured using Sorbothane ® (available only in the USA) recognized worldwide as the ultimate material for attenuating shock, isolating vibration and damping noise. No synthetic rubber or polymer can dissipate energy as effectively.

• 3 vibration suppression pads go under your tripod legs to stabilize your telescope and prevent unwanted shaking
• Made with Sorbothane" only available in the USA. Cheap imitations use silicon which do not absorb shock and may melt in the Sun.
• Engineered by Celestron specifically to dampen vibrations
• Works on any surface

Specifications

ZWO ASI6781MC

ZWO ASI678MC adopts Sony's Latest generation sensor IMX678 with excellent near-infrared response. With the advantages of Large full well capacity, high dynamic range and low readout noise, this camera has been tested and found to have perfect performance in planetary imaging, solar and lunar imaging.

Clear in low light

Thanks to the back-illuminated sensor structure and advanced pixel techno[ogy, the camera has very low readout noise and an ultra-high sensitivity. Especially in Low light conditions, the camera performs very well and is able to capture very clear images of celestial objects.

STARVIS 2

ZWO ASI678MC can be regarded as an upgrade of ASI178MC. It adopts the latest SONY IMX678 sensor with advanced STARVIS 2 technology. Compared to ASI178MC, this camera features zero amp glow, lower readout noise and higher sensitivity. The dark current noise is greatly decreased; the performance of near-infrared is greatly improved.

USB 3.0 & 256M DDR3 Memory

The camera is equipped with a USB 3.0 transmission interface and a built-in 256MB DDR3 cache to ensure stable and secure data transmission. Under Long exposure, it effectively avoids frame dropping and greatly reduces the glow effect caused by slow reading speed.

Upgraded Model

The ZWO ASI678MC is an upgraded product of the ASI178MC. Compared to the ASI178MC, the ASI678MC has lower read noise, lower dark noise, and no amp glow.

No Amp Glow

ZWO ASI678MC exhibits zero amp glow, no matter how long the exposure and how high the gain value is. Since it is implemented directly at the hardware level, it does not require software control.

HCG Mode

The camera has a built-in I-ICG mode, which can effectively reduce readout noise at high gain. This allows the camera to maintain the same high dynamic range as it does at [ow gain. When the gain is 182, the I-ICG mode is automatically turned on. The readout noise is as low as 0.8e, and the dynamic range can still reach a level close to 12bit.

Quantum Efficiency

The QE curve and readout noise are very important parameters to measure the camera's performance. Higher QE and tower readout noise are necessary to improve the image signal-to-noise ratio.

Dark Current Noise

ASI678MC has much lower dark current noises than ASI178, bringing it has better image signal-to-noise ratios. If we compare the darks frames captured with these two cameras, it can be easily found that the frame from ASI678 has much Less noise and rooks much smoother.

Instruction Manual

SKU: ZWO-ASI678MC

ZWO EAF Bracket C11-C14 for Celestron Scopes

(this part is defined as optional accessories for ZWO EAF)

This bracket is designed to work with C11, C14 Celestron SCT scopes. You can directly connect it to the scopes.

The ZWO EAF Bracket C11-C14 is CNC milled from an aircraft graded aluminium block with an anodised finish.

Takes 15minutes to fit.

Fitting hardware supplied

Installation instructions included

Whats in the box?

Flexible coupling x1

Motor bracket x1

M4-8mm x2

M3-35mm x3

M4-35mm x3

Hand control and Temperature Sensor sold separately

The SkyWatcher HEQ5 PRO Dual Saddle Go-To Mount represents the ultimate evolution of the EQ5 mount. With a mount head weight of 10 kg this professional mount is ideal to be carried anywhere in search of dark skies and solar eclipses. The integrated bubble level and the adjustable tripod legs make the levelling easy, the azimuth and altitude axis can be fine adjusted for a precise polar alignment. On top of that, the included polar scope included allows an extremely precise polar alignment that helps to drastically improve the quality of tracking, especially for astrophotography.

The exceptional SynScan Go-To system allows full control of both R.A. and Dec. axes with 9 slew speeds and 5 arcminute pointing precision, allowing you to quickly and accurately locate objects across the night sky. The Go-To system can automatically slew the telescope on command toward planets, stars, nebulae, galaxies, clusters and much more. The SynScan has 42,900 memorised celestial objects for an amazing journey in the night sky. The Deep Sky Tour function suggests a list of the most interesting deep sky objects currently visible, so even the novice astronomer can easily observe faint objects at the touch of a button.
The HEQ5 Pro is designed for astrophotography featuring an auto-guide port and compatibility with computer control software. The 10kg payload capacity will handle telescopes of medium dimension such as 200mm reflectors or 150mm refractors.

SkyWatcher HEQ5 PRO Dual Features

• Easy-to-control heavy-duty mount
• Now with Dual Saddle
• Go-To German Equatorial Mount with SynScan
• Ideal for astrophotography
• Adjustable steel tripod with an accessory tray
• Fine adjustments of latitude and azimuth for precise polar alignment
• Bubble level for perfect levelling
• Aluminium setting circle dials allow for quick target acquisition via celestial coordinates
• Worm gear tracking controls provide full 360° manipulation of the RA and DEC axis
• V style telescope connection
• Minimal vibrations
• 5 Years Sky-Watcher Limited Warranty

SynScan Features:

• Database with 42,900+ objects
• Messier, Caldwell, NGC, IC & SAO catalogues, Named Stars, Double Stars, Variable Stars, Named Stars
• One, Two and Three Stars or Brightest Star Alignment
• Autoguiding feature for astrophotography
• Pointing Accuracy Enhancement feature (PAE)
• Permanent Periodic Error Correction (PPEC)
• Unknown Object Identification feature
• Pointing accuracy up to 5 arc min
• Tracking rates: Sidereal, Lunar, Solar
• Slewing speeds: 1x, 2x, 16x, 32x, 64x, 128x, 400x, 500x, 600x, 800x (3.4°/sec)
• Motor type: DC Servo Motors

In The Box:

• Sky-Watcher HEQ5 PRO Dual Mount
• Dual Telescope Saddle
• Steel Tripod
• Accessory Tray
• Integrated Counterweight Bar
• Polar scope (South and North Hemispheres)
• SynScan Hand Controller and Cable
• Counterweights
• Power Supply Cord (Lighter Plug)
• User Manual

Specifications

Enjoy close up views of nature anytime with the Kowa TSN-500 spotting scope.

Small and light enough to always be with you whether at home, the park, by the water or heading out into the bush. See flowers and insects with incredible detail using the close focus capabilities and ideal for whale watching. A responsive focus wheel and smooth 20-40x twist zoom makes operation easy for any age.

Kowa optical technology produces high resolution and clarity even in such a compact optic making a moment more memorable and immersive, then capture it forever with your smartphone using the optional Kowa smartphone adapter.

TINY SIZE - MASSIVE PERFORMANCE

The TSN-500 series scope may be tiny but optically it punches well above its (400g) weight! Kowa optical technology squeezes out as much light transmission and resolution possible for an objective lens of this size using state of the art lens coatings. Images are clear and bright with great detail.

FULLY WATERPROOF BODY

To keep the body of the TSN-500 series scope as light as possible, an advanced polycarbonate material is used whilst retaining a rugged strength to protect the optics and engineering inside. The body is fully waterproof and nitrogen filled to prevent fogging in extreme temperatures. All in all - it's a tough little cookie!

A SCOPE THAT FITS IN THE PALM OF YOUR HAND

Measuring just a mere 239mm in length and weighing only 400g (TSN-501 model), the TSN-500 is one of the smallest and lightest spotting scopes on the market. Even at this small size, Kowa have managed to create an ultra compact optic that still delivers great optical quality. Take in your back pack, on holiday abroad or even in your glovebox - never miss a moment with the Kowa TSN-500. At the design stage, every detail was considered to make the TSN-500 as compact as possible.

EASY TO USE FOR ALL AGES

With a built in twist 20-40x zoom lens and a smooth, responsive focus wheel, the TSN-500 spotting scope series really can be enjoyed by all ages. Simple and elegant design and operation combined with an ultra compact lightweight body makes the scope super portable for those wishing to travel light and carry less equipment whilst still enjoying great optical quality at an incredible price.

CLOSE FOCUS REVEALS A NEW WORLD

The Kowa TSN-500 series spotting scope can focus down to just 2.5m - this incredible close focus performance brings the secret world of flowers and insects in to all its glory. See incredible detail of this micro world that you would not normally see. Imagine observing a flower head at 40x optical zoom standing just 2.5m away from your subject!

AT A GLANCE

1. 20-40x zoom eyepiece
2. Focus wheel
3. Tripod mount
4. 50mm fully multicoated objective lens

WHAT'S IN THE BOX

• TSN-501 20-40x angled spotting scope
• Objective lens cap
• Eyepiece cap
• Instruction manual

Conduct dozens of your own experiments with the 28 Piece Celestron Microscope Kit. Includes a metal bodied microscope with 3 objective lenses (100x, 600x, and 1200x). Examine the 5 prepared slides or create your own using the 7 blank slides and cover slips. Also includes fun accessories like a 2x magnifying glass, plastic scalpel, and more.

• Beginner set with metal bodied biological microscope
• Blow molded, rugged carry case for portability and protection
• 3 objective lenses for high power viewing - 100x, 600x, and 1200x
• 7 blank slides, 5 prepared specimen slides, and 7 slide cover slips and labels
• Multiple lab accessories to get you experimenting right away:
  • Plastic scalpel
  • Tweezers
  • Pointer
  • 2x magnifier
  • Sea salt samples

Celestron’s EdgeHD reducers feature a custom 4-element optical design engineered to maintain the flat-field performance of our award winning EdgeHD optical system. Unlike generic reducers, our premium reducers provide substantial back focus to accommodate an assortment of imaging accessories.

EdgeHD reducers offer high index optical elements, including extra low dispersion, exotic Lanthanum elements, which provide high contrast viewing while minimizing chromatic aberration. All air to glass lens surfaces feature multiple layers of coating for maximum light transmission and color correction and contain blacken edges to minimize internal reflection and maximize image contrast. Large diameter lens elements, up to 60 mm clear aperture, ensure that the optimized image circle remains at a generous 42 mm for use with large CCD sensors.

Incorporating computer assisted CNC machined aluminum housing, for precise spacing and alignment of optical elements, and threaded metal covers on the lens assembly to protect your investment from dust and scratches, our reducers offer you an outstanding mechanical design.

With the fastar option on all EdgeHD optical systems, coupled with the .7x reducer, your telescope becomes the most complete imaging system available in its price range today.

Performance

Design: 4-element optical layout designed specifically for the EdgeHD 9.25" to maintain the flat-field performance of the EdgeHD optical design

Maintains the same back focus as when used at f/10: Unlike generic reducers the EdgeHD .7x provides generous back focus to accommodate additional accessories and a wide variety of cameras. Also allows use of existing EdgeHD T-Adapters and other Celestron imaging accessories

One full F-Stop faster than f/10: Reduces the exposure time by one-half to capture the same brightness of object

Increase field of view by 43%: Better for capturing wide field images of larger galaxies and nebulae

Glass

Lanthanum Glass Elements: EdgeHD reducer uses "rare earth" Lanthanum glass elements for clear, high contrast viewing while minimizing chromatic aberration

Fully multi-coated lens elements: All air-to-glass surfaces have multiple layers of coating for maximum light transmission and color correction

Blacken edges: All lens elements have blacken edges to minimize internal reflection and maximize contrast

Full Frame Design

Threads directly onto the 3.25" threads of the EdgeHD optical tube: Reduces mechanical vignetting and allows for use with larger (full frame) sensors and Off-Axis Guiders

Clear aperture: 60 mm clear aperture lens optimized for a 42 mm image circle for use with large CCD sensors.

Mechanical Design

Machined aluminum housing: Computer assisted CNC machined aluminum housing for precise spacing and alignment of the optical elements.

Threaded metal covers for both ends of the lens assembly: To protect your investment from unwanted dust and scratches.

Versatility

Fastar compatibility and f/2 imaging with optional accessory: the EdgeHD is the most complete imaging system in its price range.

ZEISS Terra® ED binoculars are robust, reliable and easy to use. Their state-of-the-art and sleek design makes them not only light but comfortably compact. The highest optical precision and the hydrophobic multicoating guarantee brilliant images down to the very last detail. The Terra ED binoculars are waterproof and nitrogen-filled, making them rough and ready. Terra ED binoculars are excellent value for money, making them the perfect entry into the world of ZEISS.

A bright image, outstanding resolution of details and comfortable viewing characteristics. In combination with optimum ease of handling, these perfectly describe the outstanding properties of the Terra ED 42.

High quality, fast refractors have a lot going for them when it comes to astrophotography but they come with a downside - field curvature. This is where the image comes to sharp focus on a curved surface. The problem is that the sensors in cameras are flat. The larger the sensor - like those used in cameras with APS-C sized or larger sensors or DSLR cameras - the more effect is noticed.

A field flattener brings the image to focus on a flat surface, like your camera's sensor. At the same time, the basic optical performance of your telescope remains the same.

You will need 55mm of backfocus.

The Bintel T-thread Spacer Ring Kit (sold separately) is recommended to achieve proper distance for use with CMOS imagers.

Use with a DSLR only requires a T-ring for the camera (T-ring sold separately).

Reinforced aluminium construction

Foam: Base: Dice pre-cut

Lid: Profile-egg foam

Carry handle

Lockable (2x keys supplied)

Dimensions

Width - 400mm

Height - 90 mm

Depth - 250 mm

Annals of the Deep Sky - Vol 9 is a comprehensive reference that guides amateur and semipro astronomers into every mind-boggling corner of the observational universe. Each volume presents extensive descriptions of prominent stars and deep-sky objects. No other popular work in astronomy provides the comprehensive historical background and astrophysical appraisals of prominent stars and celestial objects.

This volume is dedicated to the Milky Way’s nearest and largest satellite galaxies, the Magellanic Clouds. Throughout history they have been the subject of awe and wonder, catching the eye of Indigenous peoples of Australia and New Zealand, 16th century mariners, and astronomy’s pioneer observers such as Nicolas-Louis de Lacaille, James Dunlop, and John Herschel. In the late 19th and early 20th centuries, northern astronomers began traveling to the Southern Hemisphere to photograph, map out, and study the celestial constituents of what they referred to as Nubecula Major and Nubecula Minor. This book presents not only a thorough historical account of the clouds dating back 40,000 years, but also how astronomers’ ideas of the Clouds have changed over the decades — particularly on the Clouds’ origins, interactions with the Milky Way, and the quizzical aspects of star formation posed by their many unusual clusters and H II regions. Come discover the observational richness and astrophysical conundrums that are the Magellanic Clouds, true treasure islands lying just beyond our Galactic shores.

Annals of the Deep Sky - Vol 9 also includes two special fold-out maps for exploring the Magellanic Clouds in more detail, one showing the Large Magellanic Cloud and the other the Small Magellanic Cloud plus extra detail on the Tarantula Nebula, the star-forming region also known as 30 Doradus.

Author Jeff Kanipe has released the latest edition of this great series and for those of us in the South we are blessed. Volume 9 covers the Magellanic Clouds. Definitely will be in my Library of Southern Hemisphere books, can’t wait.

SKU:WBANN9

The RC II series of binoculars are extremely compact and lightweight, featuring a sophisticated design. These binoculars place emphasis on portability and can be folded for easy carrying. A range of colour variations is available to suit your personal preference.

They might be small - but are powerful for their size and offer remarkably clear views.

• 8x magnification
• Waterproof
• Foldable and ultra-compact
• Stylish outdoor design
• Rubber coated for convenient grip
• Multi-coated lenses for maximum brightness and contrast
• Convenient centre-focus knob for easy focusing
• Fully multi-coated optics
• Nitrogen‑filled body for waterproof/fogproof/dirtproof performance
• Built-in dioptric correction adjusts to individual eyesight
• Size W x H x D (mm): 107 x 88 x 38
• Weight: 215 g

The affordable Orion Saturn Map & Observing Guide is a wonderful tool for backyard astronomers of all skill levels who want to enrich their observations and understanding of this unique gas giant planet and its spectacular ring system. We've packed the tri-fold Saturn Map & Observing Guide with beautiful images and useful tips to help you get the most out of each view of Saturn. With this Map & Observing Guide at your side, you'll learn interesting information about Saturn's many moons, its extensive ring system, ring tilt cycle, and more. The Map will help you learn to identify light and dark atmospheric features of Saturn using official nomenclature. You'll appreciate the thorough list of recommended filters to help enhance visual views and astrophotos of Saturn, and the detailed list of all upcoming conjunctions and oppositions of Saturn from 2014 through 2020 will help you plan ahead to catch these interesting events.

The Saturn Map & Observing Guide measures 25.25" x 11" when fully unfolded, and folds up to 8.5" x 11". The tri-fold Saturn Map & Observing Guide is plastic laminated for long-lasting durability as well as protection against dew, dirt, and the occasional coffee spill.

• Includes lists of all Saturn oppositions, observable conjunctions from 2014 to 2020
• Lists best filters for visual observation and astrophotography of Saturn
• Plastic-laminated for durability, the Saturn Map measures 25.25" x 11" when fully unfolded, and folds up to 8.5" x 11" for easy portability

Losmandy DM10 Dovetail Plate

The Dovetail Plates are the heart of the Losmandy Secondary System. 0.5" x 4.0" x length of the tube assembly.

Dovetail plates may be mounted to the top and bottom of tube assembly for mounting of all D series accessories, making it possible to use both sides of tube for equipment.

The dovetail plates, like all accessories in the Losmandy line, are machined for lightness and rigidity from aluminium stock, then black anodized for a tough, corrosion free surface.

Meade dovetail plate for 10", bolts to existing holes.

Includes curved blocks for precision fit to the tube assembly.

Weight:. 2.5 lbs.
Length: 17.25"
Hole Separation: 16.0"/16.50"
Height:. top of tube to top of dovetail plate 1.00"
Thickness: .6"

Part # DM10

The professional-level Celestron LCD Digital Microscope II is a biological LCD microscope at an affordable price. With fully achromatic lens objectives, a mechanical stage, 3.5” full color TFT screen and 5MP CMOS sensor, the LCD Digital Microscope II allows for high-resolution imaging of specimen slides. The microscope even includes a 1GB SD card, enough storage to capture over 600 high-resolution images for lab reports, papers, lesson, and more.

Great for the discriminating professional or serious hobbyist, the LCD Digital Microscope II is ideal for labs, schools and research institutions.

Included Accessories

• 1GB SD card
• Dust cover
• Rugged canvas carrying case with shoulder strap
• 5 prepared slides
• 4 plug, multi-country AC adapter

• Professional digital biological microscope
• Full color 3.5" TFT LCD screen with onboard software
• Built-in 5MP digital camera captures high-resolution images and 30 fps SD video of your specimen
• Fully adjustable mechanical stage for easy slide movement
• 180° rotating head for easy sharing of images
• Rotating objective lens turret 3 lens powers: 4x, 10x, and 40x
• Camera sensor acts as 10x eyepiece lens, yielding 40x, 100x, and 400x powers
• 4x digital zoom for magnification up to 1600x
• Measuring reticle for comparing specimen sizes
• 2GB SD card included so you can save up to 620 high-resolution images
• TV output for display on large monitors for classroom or lab environment
• Included accessories: 1GB SD card, dust cover, rugged canvas carrying case with shoulder strap, 5 prepared slides, 4 plug international AC adapter

SKU: 44341

Instruction Manual

Powerpoints are hard to find when you are out in the field. The Powertech Cigarette Lighter Double Adapter gives you the option of another power socket so that you can run both the scope and dew heater from the same battery connection.

Can use 5amp per side for a maximum of 10 amps.

10amp glass type fuse .
