Premium Optics with HD Concept
The optical excellence of the Conquest HDX is based on the HD concept: a perfectly balanced optical system that combines selected coatings, lenses and a finely tuned optical design. It enables 90 % light transmission for the brightest images, color fidelity for true-to-life images without color fringing and color casts for perfect identification and sharpness from edge to edge for a clear and detailed image across the entire field-of-view.
Robust and durable design
The Conquest HDX is built to last in any environment, whether it's extreme temperatures, wet conditions, or direct sunlight. Its durable, waterproof, and shockproof features are attributed to its robust mechanical design and lightweight magnesium housing. Additionally, it's covered with a protective rubber armoring that provides a perfect grip under any circumstances.
Carefully thought-out ergonomics
The carefully thought-out ergonomics enable comfortable handling during longer periods of observation thanks to the non-slip grip and the smooth and precise focusing wheel. Adjustable eyecups and lockable diopter settings ensure a customized viewing experience.
A clear view, whatever the weather
There are always exciting things to be seen in the world of nature – even in wet weather. This is why ZEISS developed LotuTec®. A coating for the lenses of binoculars and spotting scopes that enables a clear and unhindered view in all weather conditions.
ZEISS T* Coating
ZEISS T* coating is a guarantee of the brilliant, high-contrast images which you will experience above all in adverse light conditions and in the twilight. Behind it, however, there is no specific formula for building up the layers. Instead, it is a technology that is constantly adjusted to suit new glass materials and requirements, which varies from lens to lens.
Specifications
| Magnification | 15 × |
| Effective lens diameter | 56 mm |
| Light transmission | 90% |
| Exit pupil diameter | 3.7 mm |
| Twilight factor | 29.0 |
| Field of view at 1,000 m (yds) | 80m |
| Subjective viewing angle | 69° Ww |
| Close focusing distance | 3.5 m (11.5 ft) |
| Diopter adjustment range | − 4.0 | + 4.0 dpt |
| Exit pupil distance | 18 mm |
| Pupil distance | 54 – 74 mm |
| Lens type | HD |
| Prism system | Abbe-König |
Features
| LotuTec | Nitrogen filled | Yes|Yes |
| Water resistance | 400 mbar |
Dimensions
| Operating temperature | − 20°C | + 63°C |
| Width at an interpupillary distance of 65 mm | 145mm |
| Weight | 1.25kg |
| Length | 210mm |
