UHD optics and anti-reflective coatings
The UHD optical system is designed to reduce colour fringing and retain fine detail. Anti-reflective coatings help light pass through the lenses. The full-size UHD design uses Abbe-Koenig roof prisms.
Skeleton text
Skeleton text
Skeleton text
Skeleton text
Skeleton text
Skeleton text
Skeleton text
Store locator
WANT TO KNOW MORE ABOUT THIS PRODUCT?
Let Gemini, ChatGPT or Claude help you. Click a button and ask away.
Razor UHD 18x56: the view explained
18xmagnification
Bring distant detail closer
The Vortex Razor UHD 18x56 binoculars give 18x magnification for observing distant wildlife and landscape detail.
56 mmobjective lenses
56 mm front lenses
The second number is the diameter of each objective lens, which gathers light for the view.
3.7°field of view
Know how much fits in the view
At a distance of 1,000 m, the view spans approximately 64.7 m. This is the width of the scene visible without moving the binoculars.
UHD optics in a magnesium body
UHD optics and anti-reflective coatings
The UHD optical system is designed to reduce colour fringing and retain fine detail. Anti-reflective coatings help light pass through the lenses. The full-size UHD design uses Abbe-Koenig roof prisms.
Magnesium body, open hinge
A magnesium chassis combines strength with reduced weight. The open hinge and rubber armour give you room to hold the binoculars securely.
Sealed body, protected lenses
O-ring sealing and argon purging provide waterproof and fogproof performance. ArmorTek coatings help protect exposed lenses against scratches, oil and dirt.
Good to know
Adjust the view to your eyes
Twist-up eyecups support viewing with or without glasses. Eye relief is 18 mm; the hinge adjusts from 56 to 76 mm to match eye spacing.
Set the diopter, then use centre focus
The locking diopter on the right eyepiece compensates for differences between your eyes. The centre focus wheel then adjusts both barrels together.
Add support for longer viewing
A tripod adapter lets you use a tripod or car-window mount. The adapter and support are separate accessories. With 18x magnification, a supported setup is a sensible choice for extended viewing.
Vortex VIP warranty in Australia
Vortex VIP lifetime cover provides repair or replacement for damaged or defective products.
ExclusionsLoss, theft, deliberate damage and cosmetic damage that does not affect performance are excluded. Grey-market purchases are not covered.
Australian claimsClaims go through the dealer or distributor in the country of purchase. See the Australian Vortex VIP warranty and claim form for details.
Specifications
Optics
Magnification
18x
Objective Lens Diameter
56 mm
Eye Relief
18 mm
Angular Field of View
3.7°
Linear Field of View
Approx. 64.7 m at 1,000 m (194 ft at 1,000 yd)
Close Focus
Approx. 3.05 m (10 ft)
Handling
Interpupillary Distance
56–76 mm
Height
Approx. 213.4 mm (8.4 in)
Width
Approx. 157.5 mm (6.2 in)
Net weight
Approx. 1191 g (42 oz), binocular only
