与 CMOS 相机相比，使用 CCD 芯片进行深空成像有很多优势。如果您想了解更多信息，请阅读此处的 BINTEL 技术文章。

请注意，本相机使用“1 级”CCD 芯片。

规格

• CCD 类型：索尼 ICX674ALG (单色) EXview CCD，具有超低暗电流和垂直防晕功能。
• CCD 全分辨率像素数据：像素大小：4.54uM x 4.54uM，图像格式：1940 x 1460 像素
• CCD 图像区域：8.81mm（水平）x 6.63mm（垂直）。
• CCD 质量：1 级或更好 - 无坏列、无坏点、“热”像素不超过 50 个（<10 秒内饱和）。
• 光谱响应：QE 最大值为 580nM（~77%），50% 下降为 360nM 和 770nM。
• 读出噪声：通常仅为 3.5 电子 RMS
• 满阱容量：大于 17,000 e-（未分箱）
• 抗晕光：过载裕度大于800x。
• 暗电流：小于 0.003 电子/秒@-10C CCD 温度。
• 数据格式：16位。
• 系统增益：0.3 个电子/ADU
• 计算机接口：内置USB 2.0兼容接口。
• 图像下载时间：全分辨率下通常为 2 秒。
• 电源要求：115VAC/240VAC @ 12VA，或 12VDC @ 900mA 最大。
• 冷却系统：通过热电冷却器调节设定点冷却供应，使CCD温度至少比环境温度低约-40C。
• 尺寸：75 x 70mm 黑色阳极氧化铝筒，CCD 窗口端有 42mm“T2”螺纹，后部有输入/输出插头。提供 CCD 对准螺钉，用于将芯片设置为与焦平面平行。
• 重量：约450克。

产品手册Trius-PRO-674-手册

产品数据表2022-SX-TRIUS-PRO-蓝色-摄像头-规格

与CMOS相机相比，使用CCD芯片进行深空成像有很多优势。

请注意，本相机使用“1 级”CCD 芯片。

规格

• CCD 类型：ICX825AL EXview II CCD，具有超低暗电流和垂直防晕染功能。
• CCD 全分辨率像素数据：像素大小：6.45uM x 6.45uM，图像格式：1392 x 1040 像素
• CCD 图像区域：8.98mm（水平）x 6.7mm（垂直）。
• CCD 质量：1 级或更好 - 无坏列、无坏点、“热”像素不超过 50 个（<10 秒内饱和）。
• 光谱响应：QE 最大值为 580nM（~75%），50% 下降为 360nM 和 770nM。
• 读出噪声：通常仅为 3.5 个电子。
• 满阱容量：大于 23,000 e-（未分箱）
• 抗晕光：过载裕度大于800x。
• 暗电流：小于 0.002 电子/秒@-10C CCD 温度。
• 数据格式：16位。
• 系统增益：0.3 个电子/ADU
• 计算机接口：内置USB 2.0兼容接口。
• 图像下载时间：全分辨率下通常为0.6 秒。
• 电源要求：115VAC/240VAC @ 12VA，或 12VDC @ 900mA 最大。
• 冷却系统：通过热电冷却器调节设定点冷却供应，使 CCD 温度至少比环境温度低 >-40C。
• 尺寸：75 x 70mm 黑色阳极氧化铝筒，CCD 窗口端有 42mm“T2”螺纹，后部有输入/输出插头。提供 CCD 对准螺钉，用于将芯片设置为与焦平面平行。
• 重量：约450克

产品手册Trius-PRO-825-手册

产品数据表2022-SX-TRIUS-PRO-蓝色-摄像头-规格

APO140FL F/7 于 2017 年首次亮相，旨在向 TEC 最早的设计之一 APO140ED 致敬，并迅速成为 TEC 最受欢迎的型号。

• APO140FL F/7 采用油隔复消色差三片式物镜，中间元件为萤石 (CaF ₂ )，可实现针对视觉使用和成像优化的色彩校正。这种油隔三片式设计与物镜所有表面的多层涂层相结合，可确保最大程度的透光率。
• 物镜安装在铝制容器内，具有出色的温度调节性能，同时重量轻且坚固。
• 光学组件位于一个轻质铝管中，该铝管的整个内部都采用了防反射涂层和锋利边缘的挡板，并且无需考虑准直——在望远镜离开 TEC 后，无需进行任何调整。
• 此外，干净利落的全白组装彰显了 TEC 一贯的优雅手工品质。这款紧凑而永恒的设计将带来深厚的对比度和丰富自然的色彩。
• 每台 APO140FL F/7 都配备了 Starlight Instruments FTF#3545 Feather Touch 调焦器，该调焦器是与 TEC 合作设计的。这是 Starlight Instruments 最大的旋转调焦器，具有粗调和微调 9:1 行星减速组件。
  • APO140FL F/7 可应要求安装到其他调焦器型号。请联系 TEC 确认所需调焦器是否适合所需 TEC 型号。
• 2 英寸锁定金属夹头对温度波动不敏感，并能以高精度和同心度保持负载。
• 能够容纳多种目镜和支架。

TEC APO140FL F/7 采用经典折射镜设计，设计简洁，不折不扣，让大自然的奇观不言而喻。所有价格和供货情况如有变更，恕不另行通知

推荐配件；

• 精密可调管环
• 9 英寸燕尾板和手柄方便运输，并可与大多数支架无缝贴合。
• 焦距缩减校正器将 F/7 比率转换为 F/6.2，后焦距为 115 毫米。
• TEC运输箱可方便观察地点之间的运输。
• TEC 紧凑型箱，方便提起和运输。
• 10×60 Baader Vario 寻星镜，配有 TEC 寻星镜支架和用于望远镜安装的底座。
• 7×50 Vixen 寻星镜，配有TEC 寻星镜支架和用于望远镜安装的底座。
• Gutekunst 紧凑型大气色散校正器 (ADC)。

测试和质量保证

TEC 望远镜经过严格测试，以确保顶级品质性能。整个玻璃生产过程中都使用牛顿环，然后我们使用干涉仪纠正任何剩余的缺陷。然后对每台望远镜进行严格测试，以达到最佳的斯特列尔比。请放心，您的望远镜已经过优化，光学性能尽可能完美。如果物镜没有达到 Yuri 的期望，望远镜将不会发货。作为一项严格政策，TEC 不会发布望远镜测试报告。

虽然物镜在干涉控制下经过微调以满足最高的光学标准，但物镜和镜筒组件中可能存在外观缺陷。请放心，望远镜中的任何缺陷均已确定不会影响光学性能。

TEC 管环非常轻巧耐用，一套两个环适用于 APO180FL F/7。管环采用 CNC 加工而成，边缘干净，采用耐刮擦的黑色阳极氧化铝。它们配有可调节的不锈钢闩锁，能够安装 TEC 燕尾板、Losmandy 板和 AP 板，以实现牢固安装。每个环都包含一个上部底座、一个可调节闩锁和一个下部底座。管环的上部底座还连接到 TEC 提手，方便运输。

TEC 硬盒在美国制造，内部填充硬泡沫，泡沫上预先切好部分，以便紧密贴合
适合。坚硬的外壳确保在运输过程中为 APO180FL 提供最佳保护，同时保持
总重量不超过 80 磅。它可轻松容纳以下配件，当连接到
APO180FL；管环、12 英寸燕尾板、12 英寸手柄、寻星镜、2 英寸 AP 对角线和最多五个 2 英寸目镜。

William Optics DSD 245mm 安装板的两侧均采用 Vixen 和 Arca Swiss 设计。该板还具有三个 1/4"-20 螺纹孔、两个 3/8"-16 螺纹孔和三个无螺纹槽。

• 长度：245 毫米
• 顶部宽度：38 毫米
• 底部宽度：41.7 毫米

Step up to Losmandy's modular family of Precision Equatorial Mounts. With 30+ years of proven field use and continuous improvements, Losmandy mounts are the choice of enthusiasts, serious amateurs and professionals who want great value in a mount that delivers exceptional performance. Losmandy is the only modular

mount system with the versatility to mix and match axis to right-size or upgrade your mount.

All Losmandy modular mounts feature the Gemini II, one of the most advanced astronomical computers available today.

Gemini II includes connectivity to all of today’s popular software and devices. Designed, manufactured, and performance hand-tuned in the USA.

PERFORMANCE

- ± 5 arcsecond or better uncorrected tracking (corrected PE often ± 2.5

arcsecond or better)

- Each mount individually hand-tuned at factory for optimum performance

- Instrument weight capacity: 75lbs (34kg) imaging, 90lb (40kg) visual

- Supports altitudes from 12° to 72° PRECISION COMPUTERIZED GOTO AND TRACKING

- Gemini II astronomical computer, version 5

- 42,000+ object database

- Precision pointing and tracking

- Tracking rates: sidereal, king, lunar, solar, terrestrial comet, closed loop

- Intuitive touch screen hand controller with day/twilight/night modes

- Built-in wizards for polar alignment, periodic error correction, and model building

- Built-in permanent periodic error correction

- Goto with accuracy up to ½ arcminute

CONNECTIVITY

- Mature reliable drivers for Windows, Mac, Linux including ASCOM and INDI

- USB, Ethernet, Serial (also supports SkyFi, SkyWire, WiFi, and Bluetooth adapters)

EASE OF USE

- Verified with most modern astronomical/Astro imaging systems including Maxim DL, NINA, SGP, Voyager, TheSkyX, Stellarium, Sky Safari, Cartes DuCiel, APT, BYEOS, Nebulosity, etc.

- Variable slip clutch, both axes.

- One knob per axis design.

- Through-axis polar scope, works in northern and southern hemispheres (optional add-on)

- English, German, French & Spanish displays

- Includes quick release to separate RA and DEC for easy transport and setup

- Designed, machined, assembled, and performance-tuned in the USA

- Power 12-18v DC

MECHANICAL

- Tucked-in motors for compact design

- Unique modular system enables mount upgrades one axis at a time

- Dual supported, ball bearing housed ground High Precision Brass Worm

-  RA 6.75 inch diameter 270 tooth, DEC 5.625 inch diameter 360 tooth, 7075 aluminum worm gears

- 1¼ inch diameter stainless steel weight shaft w/safety knob

- One-piece stainless steel wormblock

- Precision-machined aluminum and stainlesssteel, black anodized

- All stainless steel hardware Includes folding HD Tripod and 1x 21lb counterweight (additional counterweights in 7lbs(3kg), 11lbs (5kg), 21lbs (9.5kg) options)

ADDITIONAL SPECIFICATIONS

- Dual-width saddle-plate fits both Losmandy "D" style and Vixen “V” style dovetail

- Equatorial head weight: DEC 16lbs (7.2kg), RA 46lbs (21kg)

iOptron CW 10kg

低纬度 (<10°) 的 CEM120 支架配备 10 公斤配重

PlaneWave L500 将我们天文台级望远镜的所有技术整合到一个紧凑的独立支架中，集多功能性、简单性和经济性于一身。在 Alt/Az 配置中，它比赤道仪更加紧凑，可以将更大的望远镜装入更小的外壳中。制造刚性 alt/az 支架所需的质量要小得多，从而节省了成本。与德国赤道仪支架不同，它无需处理子午线翻转问题，也无需在公共天文台中制造危险的突出配重。Alt/Az 使用起来更直观，无需极轴校准。此外，这是专业人士使用的方式！

Planewave L500 安装架特点：

• 每个轴上均采用直驱电机，使望远镜平稳、快速且几乎无声地移动
• 旋转速度高达每秒 50 度
• 每个轴上都有高分辨率编码器，可实现精确定位
• 零间隙
• 零周期误差
• PointXP 安装建模软件
• 封闭式电子设备
• 通过安装布线

特征：

安装系统

控制系统

运动控制

系统性能

请查看PlaneWave网站上的说明和示意图。

注意：本产品交货时间较长。如需更多信息，请发送电子邮件至education@bintel.com.au

LEICA GEOVID R 15x56

With the new generation of Geovid R rangefinder binoculars, Leica once again sets new standards. Completely redesigned and technically updated, the new Geovid R models are impressive in every detail. Leica remains true to its brand promise and its focus on the essentials – and continues to evolve as a pioneer with 30 years’ experience in rangefinding.

You don’t want to choose between powerful binocular optics and a precise rangefinder? You don’t have to: Geovid R offers the best possible combination in one product, at an attractive price. The extremely compact, lightweight premium binoculars deliver a field of view that is outstanding in their class, as well as great image detail and fascinating color fidelity.

With an improved measurement range of up to 1,800 meters/2.000 yards, you are perfectly equipped for almost any hunt. The ballistics function EHR, which outputs the equivalent horizontal distance for angle shots at up to 1,100 meters/1.200 yards, additionally facilitates an ethical shot.

The newly developed Geovid R models focus fully on Leica’s core values: powerful premium optics, precise rangefinding, maximum optomechanical reliability, and easy, intuitive operation. Thanks to highly efficient manufacturing and a focus on the essentials, you no longer have to choose between conventional binoculars and a rangefinder.

The essentials:

• Best-in-class optical performance
• Absolutely precise laser rangefinding
• Improved measurement range: up to 2,000 yds (1,800 m)
• New, up-to-date, ergonomic design
• Particularly light, compact construction

IN THE BOX

• Leica Geovid R 15x56, Contoured neoprene carrying strap, front lens, cover, eyepiece caps, cordura case, battery

LEICA GEOVID R 8x56

With the new generation of Geovid R rangefinder binoculars, Leica once again sets new standards. Completely redesigned and technically updated, the new Geovid R models are impressive in every detail. Leica remains true to its brand promise and its focus on the essentials – and continues to evolve as a pioneer with 30 years’ experience in rangefinding.

You don’t want to choose between powerful binocular optics and a precise rangefinder? You don’t have to: Geovid R offers the best possible combination in one product, at an attractive price. The extremely compact, lightweight premium binoculars deliver a field of view that is outstanding in their class, as well as great image detail and fascinating color fidelity.

With an improved measurement range of up to 1,800 meters/2.000 yards, you are perfectly equipped for almost any hunt. The ballistics function EHR, which outputs the equivalent horizontal distance for angle shots at up to 1,100 meters/1.200 yards, additionally facilitates an ethical shot.

The newly developed Geovid R models focus fully on Leica’s core values: powerful premium optics, precise rangefinding, maximum optomechanical reliability, and easy, intuitive operation. Thanks to highly efficient manufacturing and a focus on the essentials, you no longer have to choose between conventional binoculars and a rangefinder.

The essentials:

• Best-in-class optical performance
• Absolutely precise laser rangefinding
• Improved measurement range: up to 2,000 yds (1,800 m)
• New, up-to-date, ergonomic design
• Particularly light, compact construction\

IN THE BOX

• Leica Geovid R 8x56, Contoured neoprene carrying strap, front lens, cover, eyepiece caps, cordura case, battery

LEICA GEOVID R 8x42

With the new generation of Geovid R rangefinder binoculars, Leica once again sets new standards. Completely redesigned and technically updated, the new Geovid R models are impressive in every detail. Leica remains true to its brand promise and its focus on the essentials – and continues to evolve as a pioneer with 30 years’ experience in rangefinding.

You don’t want to choose between powerful binocular optics and a precise rangefinder? You don’t have to: Geovid R offers the best possible combination in one product, at an attractive price. The extremely compact, lightweight premium binoculars deliver a field of view that is outstanding in their class, as well as great image detail and fascinating color fidelity.

With an improved measurement range of up to 1,800 meters/2.000 yards, you are perfectly equipped for almost any hunt. The ballistics function EHR, which outputs the equivalent horizontal distance for angle shots at up to 1,100 meters/1.200 yards, additionally facilitates an ethical shot.

The newly developed Geovid R models focus fully on Leica’s core values: powerful premium optics, precise rangefinding, maximum optomechanical reliability, and easy, intuitive operation. Thanks to highly efficient manufacturing and a focus on the essentials, you no longer have to choose between conventional binoculars and a rangefinder.

The essentials:

• Best-in-class optical performance
• Absolutely precise laser rangefinding
• Improved measurement range: up to 2,000 yds (1,800 m)
• New, up-to-date, ergonomic design
• Particularly light, compact construction

IN THE BOX

• Leica Geovid R 8x42, Contoured neoprene carrying strap, front lens, cover, eyepiece caps, cordura case, battery

视觉使用

对于两用照相/视觉望远镜，“VISA”适配器（视觉/成像系统适配器）可接受标准 Tele Vue 2" Paracorr Type-2 的可调顶部。2" 格式在视觉上很好，因为副镜尺寸将最大出瞳直径限制在 7mm 左右。因此，f/3（与 Paracorr 一起使用时为 f/3.45）最宽的真视场目镜选择是 Tele Vue 自己的 21mm Ethos，它在 f/3.45 时可提供 6.1mm 的出瞳。

使用 DSLR 或 CCD 相机成像

如果您有 35 毫米格式 DLSR 或 CCD 相机，“VISA”适配器可接受 Tele Vue 影像系统配件。

Optec Gemini 调焦旋转器

温度补偿：

与所有 Optec 调焦器产品一样，Gemini 包含一个远程温度探头，用于自动温度补偿。只需将温度探头连接到 OTA 的线性响应区（通常是管或桁架组件）的任意位置，Gemini 就会自动使相机组件保持清晰对焦。Gemini Commander软件提供了一个方便的向导，可帮助您确定望远镜的 TC 或温度系数。

坚固紧凑的设计

为了保持重型相机套件的平整、坚固底座，Gemini 的外壳由两块平行板组成，这些平行板由 MIC-6 工具板加工而成，平整度在 0.001 英寸（25 微米）以内。七个精确的隔离垫片保持这些板之间的 2.25 英寸间隔。旋转拉管使用由高扭矩步进电机驱动的优质正时皮带以 1/2 英寸的总行程线性移动。整个套件采用漂亮的碳纤维包裹。双 RJ45 连接器可连接到 Gemini 控制集线器。独立旋转拉管由定制的 X-cage 轴承系统支撑，该系统由大型 6 毫米镀铬滚珠轴承支撑。

支持多台望远镜

Gemini前后均采用相同的 OPTEC-4300 机械接口，可轻松安装到大多数大型望远镜 OTA 上。凹陷的椭圆形点固定螺钉可与厚壁 OPTEC-4300 燕尾槽安装座形成三点直接接触。Gemini的3.75 英寸通光孔径通过每个适配器保持，即使是较大的光锥也能无晕影地穿过相机图像平面。

在摄像机方面，典型配置可能包括用于Optec-DSI 3.5 高性能垫片组的 4300 接收器，当需要额外间距时，可配置为 1/4 英寸增量。

目前设计的望远镜适配器包括对AG Optical iDK、 Ceravolo Optical Systems Astrographs、 Meade和Celestron 10 英寸及更大级别的 SCT 以及Plane Wave Secure-Fit 的支持。

多种连接方式：

Gemini 控制中心充当中央控制器，将调焦器和旋转器连接到任何控制 PC。该中心包括串行和 USB 通信端口（使用 Optec 的 USB/串行电缆）以及有线以太网网络协议作为标准配置。可以随时添加和安装可选的 WiFi 板和天线。调焦器和旋转器端口位于 Gemini 中心的顶部，12VDC 电源、网络、可选手动控制和串行连接端口位于底部。

有多种选择：

每个 Gemini 套件都配有连接所需的一切。可选手动控制器允许在望远镜旁手动访问。WiFi 附加板安装板、精密外部温度探头和电机专用电缆构成了完整的集成套件。

Gemini 和控制器的规格：

聚焦旋转器物理规格：

• 通光孔径：3.75 英寸（95 毫米）
• 后焦距使用：2.2 英寸至 2.7 英寸（55.9 毫米至 68.6 毫米）
• 调焦器行程：0.5 英寸（12.7 毫米）
• 调焦器分辨率：0.11 微米/步
• 旋转器分辨率：600 步/度
• 最小总厚度：2.2 英寸（55.9 毫米）
• 尺寸：9.4 英寸 x 7.4 英寸（239 毫米 x 187 毫米）
• 重量：6 磅 6 盎司（2.9 千克）

Gemini 控制器中心规格：

控制器中心规格：

• 长度：5.1 英寸（130 毫米）
• 宽度：3.2 英寸（81 毫米）
• 高度：1.0 英寸（27 毫米）
• 重量：10盎司（285克）
• 安装孔：四个 4-40 x 1/8" 深度（背面）
• 表壳材质：6061铝，阳极氧化黑色。

Gemini Hub 端口连接：

• 聚焦器：RJ45 插座，用于将标准 Cat-5e/Cat-6 电缆连接至聚焦器端口，
• 旋转器：RJ45 插座用于标准 Cat-5e/Cat-6 电缆连接至旋转器端口，
• 电源：12VDC 输入，2.5 x 5.5mm 插头，中心针正极，
• 网络：标准RJ45以太网插座，
• 手动控制器：RJ22 插座，用于标准电话听筒线，
• 串行：用于 Optec USB/串行电缆的 RJ12 插座（附带），
• 无线：802.11 WiFi 选项（即将推出）。

适合 Takahashi FC-60、FS-60-CB、FC-76、FS-78、FC-100、FS-102、FSQ-106、FC-125、FS-128、TOA-130、FS-152、Sky 90 以及一些 Epsilon 和 MT 型号。

For demanding long-range hunters and shooters, only the best will do. Brightest images, unique ergonomic design and the fastest, most reliable measurements - this combination makes Leica’s Geovid models pioneers in their class. Leading optical quality, superior mechanics and rugged, sleek construction give Geovid rangefinder binoculars lasting value.

The Leica Geovid  measures precisely to a true, repeatable 3,200 yards – whether on long distances, in the mountains or in difficult weather conditions. Create and save the ballistics profiles of your rifles quickly and conveniently to the app. Next simply transfer a profile to the Geovid – in an instant! These new features, coupled with Leica’s unrivaled optical qualities, give hunters and shooters a new level of confidence in any situation they encounter.

For demanding long-range hunters and shooters, only the best will do. Brightest images, unique ergonomic design and the fastest, most reliable measurements - this combination makes Leica’s Geovid models pioneers in their class. Leading optical quality, superior mechanics and rugged, sleek construction give Geovid rangefinder binoculars lasting value.

The Leica Geovid  measures precisely to a true, repeatable 3,200 yards – whether on long distances, in the mountains or in difficult weather conditions. Create and save the ballistics profiles of your rifles quickly and conveniently to the app. Next simply transfer a profile to the Geovid  – in an instant! These new features, coupled with Leica’s unrivaled optical qualities, give hunters and shooters a new level of confidence in any situation they encounter.

LEICA GEOVID PRO 8x42

The intelligent all-rounder.

Designed for daytime hunting at all distances, the rangefinders of the Leica Geovid Pro 42 series are the first choice for active hunters seeking a true all-rounder. This is the reliable ballistic solution for all close and long shots, at any time. Whether stalking in the forest at home, hunting in the vast savannah or in the mountains – with a rifle or a bow – the Leica Pro 42 models are the perfect universal companions. They feature the outstanding Perger-Porro prism system, the world-leading Applied Ballistics® software, and a precise Class 1 laser. The Geovid Pro 8 x 42 and 10 x 42 models with Bluetooth® are exceptionally powerful, multifunctional, and ergonomic. As with all Leica Geovid Pro models, the focus is on optical excellence, field-proven ballistics, and intuitive use.

The essentials:

• High-class optics and superior mechanics
• Exact and real time ballistic calculation with superior on-board Applied Ballistics® solver
• Integrated environmental sensors: Built-in air pressure, temperature and angle sensors for precise ballistic readings
• Newest Bluetooth® connectivity for quick and easy programming, setting and tracking with the Leica Ballistics App 2.0
• State-of-the-art GPS tracking solution mit LPTTM (Leica ProTrack)
• Advanced real-time precision: Pair with Kestrel® devices to get real-time wind direction and speed updates

IN THE BOX

• Leica Geovid Pro 8x42, Multitool, Quick Start Guide, Carrying Case, Neoprene Carrying Strap, Eyepiece & Objective Lens Cover, Lens Cleaning Cloth

LEICA GEOVID PRO 10X42

The intelligent all-rounder.

Designed for daytime hunting at all distances, the rangefinders of the Leica Geovid Pro 42 series are the first choice for active hunters seeking a true all-rounder. This is the reliable ballistic solution for all close and long shots, at any time. Whether stalking in the forest at home, hunting in the vast savannah or in the mountains – with a rifle or a bow – the Leica Pro 42 models are the perfect universal companions. They feature the outstanding Perger-Porro prism system, the world-leading Applied Ballistics® software, and a precise Class 1 laser. The Geovid Pro 8 x 42 and 10 x 42 models with Bluetooth® are exceptionally powerful, multifunctional, and ergonomic. As with all Leica Geovid Pro models, the focus is on optical excellence, field-proven ballistics, and intuitive use.

The essentials:

• High-class optics and superior mechanics
• Exact and real time ballistic calculation with superior on-board Applied Ballistics® solver
• Integrated environmental sensors: Built-in air pressure, temperature and angle sensors for precise ballistic readings
• Newest Bluetooth® connectivity for quick and easy programming, setting and tracking with the Leica Ballistics App 2.0
• State-of-the-art GPS tracking solution mit LPTTM (Leica ProTrack)
• Advanced real-time precision: Pair with Kestrel® devices to get real-time wind direction and speed updates

IN THE BOX

• Leica Geovid Pro 10x42, Multitool, Quick Start Guide, Carrying Case, Neoprene Carrying Strap, Eyepiece & Objective Lens Cover, Lens Cleaning Cloth

LEICA GEOVID PRO 8X56

The twilight specialist.

The Leica Geovid Pro 8 x 56 complements the revolutionary Leica Geovid Pro 32 and 42 models. Equipped with a 7-mm exit pupil and bright 56-mm objective lenses, it is the first choice for hunting in twilight. The Leica Geovid Pro 8 x 56 combines perfect optical performance with the world’s leading, sophisticated ballistics solution. The built-in Applied Ballistics® calculator takes into account all available ballistics values for accurate close- and long-range shots, factoring in angle, barometric pressure, and temperature. The powerful Class 1 laser measures targets at EHR of 10 meters to 2,950 meters in just 0.3 seconds. Comprehensive connectivity solutions make this model an indispensable companion for hunting, especially under difficult light conditions – and with unparalleled ease of use.

The essentials:

• High-class optics and superior mechanics
• Exact and real time ballistic calculation with superior on-board Applied Ballistics® solver
• Integrated environmental sensors: Built-in air pressure, temperature and angle sensors for precise ballistic readings
• Newest Bluetooth® connectivity for quick and easy programming, setting and tracking with the Leica Ballistics App 2.0
• State-of-the-art GPS tracking solution mit LPTTM (Leica ProTrack)
• Advanced real-time precision: Pair with Kestrel® devices to get real-time wind direction and speed updates

IN THE BOX

• Leica Geovid Pro 8x56, Multitool, Quick Start Guide, Carrying Case, Neoprene Carrying Strap, Eyepiece & Objective Lens Cover, Lens Cleaning Cloth

LEICA GEOVID PRO 10X32

With the introduction of the Geovid Pro 32 models Leica steps into a new era of capability and utility in laser rangefinding. The combination of our legendary optical quality and unique ranging capability with a never-before-seen compactness and on-board Applied Ballistics® software results in a groundbreaking, revolutionary rangefinding binocular.

The Leica Geovid Pro 10x32 is a genuine benchmark. Designed for hunting in the mountains, bow hunting or hunting in open field where the extra magnification is needed for identification. The most compact and powerful rangefinder binoculars in the premium class, this model features world-leading Applied Ballistics® software and a extreme precise Class 1 laser. Never, before has such a small glass packed so much optical performance with field-proven ballistics. Extremely powerful with cutting-edge technology, this rangefinder pioneer is the first choice for any active hunter who appreciates compact equipment and demands a reliable ballistic solution for all close- and long-range shots.

Compact and lightweight

Most compact super premium laser range finding binocular for min. pack size

High-Class Optics

Best optical elements for outstanding optical performance.

Applied Ballistics® on-board

The Geovid Pro 32 provides a ballistic solution up to 875 yards (Applied Ballistics® Ultralight) incl. wind correction out of the box. Upgradeable to Applied Ballistics® Elite.

Enhanced Connectivity Solutions

As an option pair to Kestrel® devices for ultimate in real-time precision. Basemap® integration gives remarkable GPS spot tracking.

Leica Ballistics App 1.0

With Leica Ballistics App powered by Applied Ballistics® the user is able to generate personal ballistics profiles, mark a target via GPS or remotely activate the rangefinder.

Laser Rangefinding Performance

Fast, precise rangefinding for reliable point-of-impact correction. The Geovid Pro offers an extremely short measuring time at enormous distances up to 2,500 yards.

IN THE BOX

• Multitool, Quick Start Guide, Carrying Case, Neoprene Carrying Strap, Eyepiece Cover, Objective Lens Cover, Lens Cleaning Cloth

LEICA GEOVID PRO 8X32

With the introduction of the Geovid Pro 32 models Leica steps into a new era of capability and utility in laser rangefinding. The combination of our legendary optical quality and unique ranging capability with a never-before-seen compactness and on-board Applied Ballistics® software results in a groundbreaking, revolutionary rangefinding binocular.

The Leica Geovid Pro 8x32 is a genuine benchmark. It is designed for stalking during the day as well as hunting journeys where less weight and size are important. The most compact and powerful rangefinder binoculars in the premium class, this model features world-leading Applied Ballistics® software and a extreme precise Class 1 laser. Never, before has such a small glass packed so much optical performance with field-proven ballistics. Extremely powerful with cutting-edge technology, this rangefinder pioneer is the first choice for any active hunter who appreciates compact equipment and demands a reliable ballistic solution for all close- and long-range shots.

Compact and lightweight

Most compact super premium laser range finding binocular for min. pack size

High-Class Optics

Best optical elements for outstanding optical performance.

Applied Ballistics® on-board

The Geovid Pro 32 provides a ballistic solution up to 875 yards (Applied Ballistics® Ultralight) incl. wind correction out of the box. Upgradeable to Applied Ballistics® Elite.

Enhanced Connectivity Solutions

As an option pair to Kestrel® devices for ultimate in real-time precision. Basemap® integration gives remarkable GPS spot tracking.

Leica Ballistics App 1.0

With Leica Ballistics App powered by Applied Ballistics® the user is able to generate personal ballistics profiles, mark a target via GPS or remotely activate the rangefinder.

Laser Rangefinding Performance

Fast, precise rangefinding for reliable point-of-impact correction. The Geovid Pro offers an extremely short measuring time at enormous distances up to 2,500 yards.

IN THE BOX

• Multitool, Quick Start Guide, Carrying Case, Neoprene Carrying Strap, Eyepiece Cover, Objective Lens Cover, Lens Cleaning Cloth

LEICA TRINOVID BCA

The right companion for ambitious users

Best resolving power and small size fit for any kind of use

The Trinovid BCA models are the most versatile of all compact binoculars. Their high-quality optics provide great resolving power in a small size, making them the perfect companion for various occasions.

Built for outstanding colour fidelity and high-contrast viewing

Leica’s innovative High Durability Coating® (HDC®) is an abrasion-resistant and transmission enhancing multi-coating, guaranteeing superior light transmission and outstanding colour fidelity.

Brilliant performance in any situation

Inspired by the powerful Trinovid series, these compact binoculars are the perfect companion wherever you go. Their robust, water-resistant construction and low weight make them ideal for outdoor activities.

Celestron X-Cel LX 系列目镜提供 60º 的视场，非常适合观测月球、行星和大量深空天体。优质的六元件光学组件采用多层高透射涂层处理，以获得清晰、锐利的图像。光学元件的边缘经过涂黑以增加对比度。所有七个 X-Cel LX 目镜均具有 16 毫米的舒适眼部缓解，并且是共焦的，这意味着您可以在观察期间更换系列中的目镜，几乎不需要或不需要额外的调焦。X-Cel LX 目镜主体由黑色阳极氧化铝制成。弹出式眼罩可轻松调整高度以适应不同的用户。将它们向一个方向转动以延长长度，向另一个方向转动以提供平坦表面，这对大多数眼镜佩戴者来说都是更好的选择。目镜筒中心周围的螺纹橡胶手柄可确保安全操作，即使在潮湿条件下或戴着厚手套的情况下也是如此。 1.25 英寸插入筒带有螺纹，可用来安装过滤器。

借助专为 RASA 设计的这款光污染成像滤镜，即使在光污染的天空下，也能充分利用 Celestron Rowe-Ackermann Schmidt Astrograph 11。无论您使用哪种相机，这款滤镜的宽大 68 毫米通光孔径都使其能够轻松容纳当今最大的传感器。这款滤镜采用机加工铝制外壳和 Schott B270 玻璃，取代了 RASA 的透明光学窗口，因此 RASA 的光学性能不会受到影响。

消除光污染，同时保持图像明亮
光污染限制了我们能够看到和拍摄的夜空范围。在光污染区域使用彩色相机拍摄时，天空辉光会降低图像质量。光污染滤镜有助于选择性地阻挡普通路灯和其他环境照明发出的光线。但大多数光污染滤镜会严重影响总光通量，导致图像暗淡，并对色彩平衡产生负面影响，导致图像显得太绿或太蓝。

RASA 的光污染成像滤镜“精准”地去除了不需要的光污染，同时尽可能多地保留有用的光谱。这意味着您仍将保留望远镜在许多波长下捕获的 90% 以上的光线。

与其他光污染抑制滤镜不同，Celestron LP RASA 成像滤镜保持相对中性的色彩平衡，因此您可以呈现星系和其他暗淡深空物体的微妙色彩。多层特殊配方的介电涂层可提供所需的透射率，而防反射涂层可最大限度地减少星晕和内部反射。

还包括一个透明塑料盒，用于在不使用时保护过滤器

单独质量测试
每个 RASA 11 光污染成像滤镜都经过单独透光测试。包装盒内有一张图表，详细说明了特定滤镜的实际透射光谱。

Tele Vue TV60 手提包

我们定制的望远镜包可让您方便、时尚地运输您的 Tele Vue 望远镜。

正如您所读到的，所有牛顿/多布森望远镜都可以从使用 Tele Vue Paracorr（抛物线校正器）消除图像中的彗形像差中受益。优化此校正的一个方面是目镜焦点（视场光阑位置）与 Paracorr 镜头最后一个表面之间的距离（当然在很小的 +/- 公差范围内）。快速牛顿望远镜使用的典型目镜的视场光阑位置可能相差多达半英寸。为了适应这些差异，我们开发了“可调顶部”。

“可调顶部”允许优化所有 Tele Vue 目镜和许多其他目镜的像差控制，只需松开螺钉并旋转可调顶部即可。目镜筒高度可升高和降低，让您保持适当的视场光阑与 Paracorr 镜头的距离。

Tele Vue PiggyCam 摄像机

将相机固定到 Piggy-Cam 上，可实现背负式摄影的最大灵活性。Piggy-Cam 的 3/8 英寸厚倾斜底板几乎可以锁定在任何角度，让您获得最令人愉悦的照片构图。

固定的 ¼"-20 锁定螺钉位于插槽中，可轻松安装任何 35 毫米相机。虽然 Piggy-cam 的 U 形安装支架专为 Tele Vue 望远镜设计，但它可轻松适应大多数望远镜

概念： Piggy-Cam 提供了一个坚固、可调节的平台，可以将相机搭载在各种望远镜上。——Al Nagler
