AP-SM Equatorial mount

The Advanced Polaris (AP) mount is ideal for beginners learning to use an equatorial mount, as well as experienced observers looking for a simple, grab-and-go setup. It securely supports your telescope's optical tube, providing a stable and comfortable observing experience. Thanks to its friction control system, the mount can be quickly and smoothly moved to your target object. A wide range of optional accessories is available to customize the AP mount to suit your observing needs..

R.A. Motor module and STAR BOOK ONE Set

The AP-SM equatorial mount comes equipped with the RA motor module and the STAR BOOK ONE set, which includes the main motor for celestial tracking and the STAR BOOK ONE controller. This set forms the core of the AP mount system. You can customize and expand your setup by adding additional modules to the RA motor module and STAR BOOK ONE base.

Stylish design

The new stylish and compact design helps break the stereotype of astronomical telescopes being bulky and difficult to use. Weighing just 3.6 kg (excluding the counterweight), the mount is lightweight and easy to handle—even with full-scale astronomical telescopes. The power supply, using four AA batteries, is built into the body, and the use of internal electrical contacts eliminates the need for external wiring that was previously exposed.

Friction control system

Simply point the target objects by moving the optical tube by hands. The friction control system allows you to manually point the telescope at the object without using knobs and clamps.

Simple polar alignment

The optional polar meter can be attached on the equatorial mount for simple polar alignment. Even beginners can quickly align polar axis. For precision alignment, the polar axis scope is usually used, but the polar meter can outperforms especially where Polaris is not visible.

Polar alignment scope PF-L

The PF-L polar alignment scope features a three-star alignment system and a built-in dark field illuminator, allowing you to perform polar alignment while looking directly through the scope. The illumination automatically turns off to conserve power.

To complement the PF-L, we provide a free app called "PFL Assist" for smartphones and tablets. This app supports polar alignment by visually indicating the correct star positions within the displayed constellation.

Power supply system focusing on mobility and comfort

The motor module operates with 4 pieces of the AA batteries which are commercially available anywhere easily, not only corresponding to the alkaline battery but also economical rechargeable batteries (Ni-MH, Ni-Cd). For long term use, a commercially available USB external power supply such as USB mobile battery or USB AC adapter can be used connecting to the provided USB Micro-B terminal.

R130Sf Newton reflector

The 130mm aperture newton reflector which is excellent in light gathering power is ideal for observation of faint nebulae and star clusters in a wide and bright field of view.

APP-TL130 tripod

The compact APP-TL130 tripod is adjustable from 60 cm to 130 cm, combining the portability of a photographic tripod with the strength of an astronomical telescope tripod. The tripod’s feet can be switched between rubber pads and metal spikes, preventing damage to floors when used indoors.

Optical tube

Drawtube

Tripod

Others

Included:

• Optical tube assembly
• AP-SM equatorial mount
• Eyepiece
• APP-TL130 tripod

At a glance

An ideal telescope for grab and go observing.
The A70Lf refractor is a basic all-around telescope that gives beginners intriguing views of lunar crators and Saturn's rings.

Specificstions

For observation of faint nebulae and star clusters in a wide and bright field of view

The 130mm aperture newtonian reflector with excellent light gathering power is ideal for observation of faint nebulae and star clutsters, particularly for beginners who wish to start astronomical life with a large aperture excellent in light gathering power.

• AP Equatorial mount

  The Advanced Polaris mount is ideally suited for beginners who want to become familiar with an equatorial mount, as well as for experienced observers looking for a simple, grab-and-go solution. The AP mount securely supports your telescope's optical tube, ensuring stable and comfortable observing. Thanks to its friction control system, the mount can be quickly and smoothly moved to your target object without the need for knobs or clamps. A wide range of optional accessories is available to customize the AP mount to meet your specific observing needs.

• Stylish design

  The new stylish and modern design breaks away from the traditionally bulky image of astronomical telescopes. Weighing just 3.6 kg (excluding the counterweight), the lightweight body makes it easy to handle even full-scale telescope setups. The power supply runs on four AA batteries, which are integrated inside the mount. Additionally, the use of internal electrical contacts eliminates the need for external wiring, offering a cleaner, more user-friendly setup compared to previous designs.

• Friction control system

  Simply aim at your target object by moving the optical tube by hand. The friction control system allows smooth, manual pointing of the telescope without the need for knobs or clamps.

• Simple polar alignment

  The optional Polar Meter can be attached to the equatorial mount for easy and quick polar alignment. Even beginners can align the polar axis with minimal effort. While a polar axis scope is typically used for more precise alignment, the Polar Meter can be more effective—especially in locations where Polaris is not visible.

• Polar alignment scope PF-L

  The PF-L polar alignment scope features a three-star alignment system and a built-in dark field illuminator, allowing you to perform polar alignment while looking directly through the scope. The illumination automatically turns off to prevent unnecessary power consumption.

  To support the PF-L scope, we offer a free app called "PFL Assist" for smartphones and tablets. This app helps users visualize the correct star positions within the constellation, making polar alignment easier and more intuitive.

• R130Sf Newton reflector

  The 130mm aperture newton reflector which is excellent in light gathering power is ideal for observation of faint nebulae and star clusters in a wide and bright field of view.

• APP-TL130 tripod

  The compact APP-TL130 tripod is adjustable between 60 cm and 130 cm, combining the portability of a photographic tripod with the strength of an astronomical telescope tripod. The tripod feet can be switched between rubber pads and metal spikes, allowing for stable use on various surfaces without damaging indoor flooring.

Optical tube

Drawtube

Tripod

Others

Best for serious astrophotographers who demand a perfect imaging platform with user-friendly functions that allow for comfortable operation.

The AXJ-A103S package comes with the quad element AX103S apochromatic system that features SD glass for uncompromising optical performance, the pinnacle of this aperture class. The mount comes with a sturdy but lightweight ASG-CB90 tripod made of carbon fiber.

•  AX103S optical tube assembly.

  The three-element objective lens, which includes a centre SD glass element, delivers crystal-clear, sharp, and high-contrast images with no noticeable false colour. Additionally, the built-in field corrector lens ensures that star images remain as small as 20 microns at the edge of the imaging field. Premium AS coatings are applied to every lens surface, enhancing visible light transmission to 99.5% (for wavelengths between 400nm and 700nm), ensuring exceptional light transmission across the entire visible spectrum.

• AXJ equatorial mount.

  The AXJ mount, equipped with the advanced Ultimate Periodic Error Correction (VPEC) system, provides highly accurate tracking with precision of +/- 4 arc seconds or better. The VPEC operates automatically during use, ensuring seamless performance. The mount's belt drive system significantly reduces backlash and minimizes motor noise, while delivering quick and stable motor response. Additionally, the AXJ mount supports a maximum payload of 22 kg.

• STAR BOOK TEN star chart go-to navigation controller.

  The STAR BOOK TEN features an intuitive "Star-Chart Go-To" system with a high-definition colour LCD display. It shows detailed information, including the telescope's position, the target, and other useful data. The night vision mode can be activated to illuminate the entire screen in red, reducing brightness to protect the observer's night vision.

• Durable and lightweight carbon tripod.

  The ASG CB90 is a compact and lightweight tripod which is constructed of durable carbon fibre legs. Also, the tripod head, leg extension part and leg brace have been reviewed completely to realize a highly stable tripod for the AXJ mount.

Optical Tube

Focuser

Tripod

Others

More light gathering power is great for viewing deep sky objects.

A combination of a 130mm Newtonian reflector and a simple and easy-to-use "Alt-Azimuth" mount that is comprised of parts of the AP equatorial mount.
